PC-11469

Plasticase Style E Plastic Case PC-11469
  • Plasticase Style E

Product Details

Model # PC-11469 Plasticase Style E Plastic Cases
  • Light gray top and bottom covers with dark gray end panels
  • Textured surface makes the box more resistant to marring
  • Included screws hold covers together which in turn capture the end panels
  • Both top and bottom covers have internal PCB mounting bosses for horizontal board mounting and card guides for vertical board mounting
  • Press-in rubber feet are included which cover the cover attachment screw heads and provide a non-slip surface
  • Decorative edge detail provides an update modern look
  • Durable UL94-HB rated ABS material
  • Easily modified by Bud
 Check Stock / Pricing Request ModificationsCompare Sizes and Models
External Size H x W x D: 1.57" x 7.87" x 11.02"
Internal Size H x W x D: 1.02" x 7.63" x 10.61"
Weight: 1.01 lbs
Color: Light Gray
RoHS Certified: Always Compliant
Type of Plastic: ABS
Flammability Rating: UL94-HB
Bosses: Yes
Card Guides: Yes

Drawing

PC-11469 Dimensions

OTHER MODELS IN THIS SERIES

Model # External Dimensions Internal Dimensions
PC-11460 1.42" x 3.74" x 6.22" 1.423.746.22 0.87" x 3.50" x 5.81"
PC-11463 1.42" x 6.14" x 7.09" 1.426.147.09 0.87" x 5.86" x 6.68"
PC-11469 1.57" x 7.87" x 11.02" 1.577.8711.02 1.02" x 7.63" x 10.61"
PC-11466 1.58" x 5.43" x 7.48" 1.585.437.48 1.02" x 5.19" x 7.07"
PC-11464 1.73" x 6.14" x 7.09" 1.736.147.09 1.18" x 5.86" x 6.68"
PC-11461 1.85" x 3.74" x 6.22" 1.853.746.22 1.30" x 3.50" x 5.81"
PC-11465 2.05" x 6.14" x 7.09" 2.056.147.09 1.50" x 5.86" x 6.68"
PC-11462 2.28" x 3.74" x 6.22" 2.283.746.22 1.73" x 3.50" x 5.81"
PC-11467 2.36" x 5.43" x 7.48" 2.365.437.48 1.81" x 5.19" x 7.07"
PC-11470 2.40" x 7.87" x 11.02" 2.407.8711.02 1.81" x 7.63" x 10.61"
PC-11468 3.15" x 5.43" x 7.48" 3.155.437.48 2.60" x 5.19" x 7.07"
PC-11471 3.15" x 7.87" x 11.02" 3.157.8711.02 2.60" x 7.63" x 10.61"
